GH-1440C /GH-1640C
Description
1. MEEHANITE cast-iron construction.
2. Rectangular guideways Y/Z with high rigidity.
3. Hardened and ground table surface.
4. Headstock swivels ±30°
5. Heavy-duty, heavy cutting.
MODEL | Unit | BM-400 | BM-500 |
Table size | mm | 1400x400 | 2000x400 |
Table travel | mm | 800(1000)x400 | 1500x620 |
Table feeds (X,Y,Z ) | mm/min | 18~627(9 steps) Rapid: 1670 | 20~2000(Variable) Rapid:3500 |
T-slot ( No./Width/Distance) | mm | 3-18-100 | 3-18-100 |
Max.load of table | kg | 800 | 2000 |
Distance from spindle to table | mm | 150~650 | 100~650 |
Distance from spindle to column | mm | 520 | 600 |
Spindle taper | ISO50 | ISO50 | |
Spindle travel | mm | 105 | 105 |
Spindle speeds | rpm | 18~1800(Variable) | 661440(12 steps) |
Main motor power | KW | 7.5 | 6.5/8 |
Overall dimensions | mm | 2290x1840x2120 | 3000x2420x2340 |
Weight | kg | 3860 | 4500 |
