1.  15" LCD display.

2.  Adopting high precision DC serve motor.

3.  Mirror processing special circuit.

4.   Automatic protection circuit for carbon deposition prevention.

5.  Multifunctional hand control box input, simple display.

6.  Z axis two-direction positioning accuracy A: 0.008/300mm.

      Z axis one-direction re-positioning accuracy R+ and R-: 0.004mm.

      Z axis of the reverse difference (loss of momentum) B: 0.006mm (ZNC 500A/700A: 0.008mm).

Electric Control Cabinet
