Max. drilling capacity

mm

φ50

φ58

Max. tapping capacity

mm

M33

M38

Spindle taper

MT.4

MT.4

Spindle travel

mm

210

220

Spindle speeds

rpm

55-1450 (18 steps)

60-1270 (12 steps)

Speed feeds (3 steps)

mm/r

0.1,   0.2, 0.3, 0.4

0.10,0.20,0.30

Distance from spindle to table

mm

80-800

30-610

Distance from spindle to base

mm

1325

915-1135

Throat dept

mm

375

400

Column dia.

mm

180

200

Table travel

mm

720/650 (auto)

395

Table size

mm

580x580

600x550

Base size

mm

860x580

600x1060

Motor power

kW

2.4/3.0

3

Packing size

mm

590x900x2250

1250x750x2450

N.W./G.W.

kg

760/860

860/950
