Max. drilling capacity

mm

φ40

Max. tapping capacity

mm

M24

Spindle taper

MT.4

Spindle travel

mm

180

Spindle speeds (18 steps)

rpm

50-1450

Speed feeds (2 steps)

mm/r

0.1; 0.2

Distance from spindle to table

mm

0- 770

Distance from spindle to base

mm

1030-   1210

Throat deep

mm

350

Column dia.

mm

150

Table travel

mm

580

Table size

mm

560x560

Base size

mm

730x500

Motor power

kW

0.85/1.5

Packing size

mm

2290x630x1090

N.W./G.W.

kg

465/550
