Max. drilling dia.

mm

Ф63

Ф80

Ф100

Max. feed force

N

30000

30000

45000

Max. spindle torque

Nm

800

800

1150

Spindle taper

MT.5

MT.6

MT.6

Spindle travel

mm

250

250

310

Spindle head travel

mm

250

250

300

Spindle speeds

rpm

40~570(9 steps)

40~570(9 steps)

26~320(6 steps)

Feed speeds

mm/r

0.1~0.78(6 steps)

0.1~0.78(6 steps)

0.096~0.717(6 steps)

Table travel

mm

300

300

300

Table size

mm

650x550

650x550

760x650

Distance from spindle to table

mm

800

800

850

Distance from spindle to column

mm

375

375

480

Main motor power

KW

5.5

7.5

7.5

Overall dimensions

mm

965x1452x2787

965x1452x2787

1465x970x3170

Weight

kg

1900

1900

3500
