Max. drilling capacity

mm

Φ25

Φ35

Φ30

Φ40

Φ50

Max. tapping capacity

mm

M16

M22

M20

M24

M30

Distance from spindle to column

mm

240

320

320

360

360

Distance from spindle to table

mm

--

--

625

590

590

Distance from spindle to base

mm

650

645

1180

1175

1170

Spindle travel

mm

110

155

155

200

240

Spindle headstock travel

mm

470

520

--

--

--

Spindle taper

MT.3

MT.4

MT.4

MT.4

MT.4

Spindle speed steps

step

6

12

12

12

12

Spindle speed range

rpm

125~2825

125~3030

125~3030

52~1400

52~1400

Spindle feeds

mm/r

--

0.1,0.2,0.3

0.1,0.2,0.3,0.4

Spindle feed type

Manual

Electro-magnetic clutch

Swivel angle of table

degree

--

--

±45°

±45°

±45°

Table travel (Manual/Auto)

--

--

560

530/410

530/410

Table size

mm

--

--

500x420

580x460

580x460

Base size

mm

310x320

370x360

370x360

445x435

445x435

Motor power

KW

0.75

1.0/1.2

1.0/1.2

2.2

3

Overall dimensions

mm

700x410x1560

850x500x1670

875x510x2140

940x680x2405

950x680x2405

Weight

kg

270

385

545

620

655
