Max. drilling dia.

mm

Φ30

Φ35

Φ40

Tapping capacity(steel/iron)

mm

M12/M16

M12/M16

M18/M32

Spindle taper

MT.3

MT.4

MT.4

Spindle travel

mm

150

150

190

Spindle speeds

(8 steps)

50Hz

rpm

75～3010

75～3010

90～1500

60Hz

rpm

90～3610

90～3610

108～1800

Spindle feeds (4 steps)

mm/r

--

0.1～0.33

0.1～0.33

Spindle feed type

Manual

Electro-magnetic clutch

Mechanical

Distance from spindle to table

mm

815

880

215～830

Distance from spindle to base

mm

1230

960～1215

1200

Column diameter

mm

100

120

140

Table size

mm

Φ500

500x350

500x350

Base size

mm

670x400

670x400

720x500

Motor power

KW

1.1/1.3

1.5/1.8

2.2

Packing size

mm

1740x600x900

1700x670x850

2170x570x930

N.W./G.W.

kg

215/240

275/290

290/310
