DHP-1500
Description
Features:
1. Milling, drilling, tapping, boring, reaming.
2. 2-step motor for wide spindle speed range.
3. CE electric control box (tapping).
4. Auto feeding, coolant system and halogen light.
5. More thicker column.
6. Tilting table: 90°
MODEL | Unit | VD40T |
Drilling capacity | mm | Φ40 |
Milling capacity | mm | Face:80, End:32 |
Tapping capacity | mm | M24 |
Spindle taper | MT.4 | |
Spindle travel | mm | 120 |
Spindle speeds (12 steps) | rpm | 75~3200 |
Spindle feeds | mm/r | 0.1, 0.18, 0.26 |
Distance from spindle to column | mm | 310 |
Distance from spindle to table | mm | 530 |
Distance from spindle to base | mm | 1180 |
Table size | mm | 730x210 |
Table travel | mm | 500x240 |
Base size | mm | 670x470 |
Column diameter | mm | Φ125 |
Main motor power | KW | 1.1/1.5 |
Coolant motor power | W | 75 |
Overall dimensions | mm | 890x570x2100 |
N.W/G.W | kg | 480/520 |
