Drilling capacity

mm

Ф40

Ф40

Milling capacity

mm

--

Face:80; End:22

Spindle taper

MT.4 or R8

MT.4 or R8

Spindle travel

mm

110

110

Spindle speeds

rpm

50~1250 (6 steps); 50~2500 (12 steps, optional)

Speed feed range

mm/r

0.12; 0.18 ,0.25

Spindle feed type

Auto-feeding

Auto-feeding

Distance from spindle to column

mm

261

261

Distance from spindle to table

mm

745

745

Distance from spindle to base

mm

1245

1245

Table size

mm

540x470

585x190

Table travel

mm

515

370x140x515

Base size

mm

635x460

635x460

Column diameter

mm

Ф115

Ф115

Main motor power

KW

1.1(1PH); 1.5(3PH)

1.1(1PH); 1.5(3PH)

N.W./G.W.

kg

320/360

340/380
