Drilling capacity

mm

Ф40

Ф40

Tapping capacity

M32

M32

Face milling

mm

--

80

Vertical milling

mm

--

22

Spindle taper

MT.4

MT.4

Spindle travel

mm

120

120

Spindle speeds

rpm

95~1600 (6 steps)

Distance from spindle to column

mm

273

273

Distance from spindle to table

mm

745

745

Distance from spindle to base

mm

1200

1245

Table size

mm

540x470

585x190

Table travel

mm

515

370x140x515

Base size

mm

690x520

690x520

Column dia.

mm

Ф115

Ф115

Main motor power

KW

0.75(1PH);  1.1(3PH)

Overall height

mm

1810

1810

Packing size

mm

720x740x1910

720x740x1910

N.W./G.W.

kg

335/375

335/375
