Drilling capacity

mm

Ф30

Ф35

Milling capacity

mm

--

--

Spindle taper

MT.3

MT.4

Spindle travel

mm

110

160

Spindle speeds

rpm

80~1600(Variable)

85~1800(Variable)

Speed feed range

mm/r

--

0.1, 0.2, 0.3

Spindle feed type

Manual

Mechanical feed

Distance from spindle to column

mm

230

320

Distance from spindle to table

mm

690

625

Distance from spindle to base

mm

1180

1180

Table size

mm

400x320

500x420

Table travel

mm

555

585

Base size

mm

340x320

370x360

Column diameter

mm

Ф 100

Ф120

Main motor power

KW

0.70/1.3 (2-speed)

1.0/1.7 (2-speed)

N.W./G.W.

kg

245/280

450/500
