Drilling capacity

mm

Φ25

Φ32

Φ25

Φ35

Tapping capacity

mm

--

--

M20

M24

Spindle taper

MT.3

MT.4

MT.3

MT.3 or MT.4

Spindle travel

mm

120

120

100

130

Spindle speeds

rpm

150~2450(12 steps)

127~2380(16 steps)

75~3200(12 steps)

Spindle feeds

mm/r

--

--

--

0.1, 0.18, 0.26

Distance from spindle to column

mm

438

510

203

310

Distance from spindle to table

mm

650

650

145~895

85~685

Distance from spindle to base

mm

1100

1100

1200

1140

Table tilting angle

360º

360º

360º

360º

Table size

mm

350x350

470x420

350x280

500x380

Base size

mm

470x360

580x430

410x550

670x470

Vice size

mm

152

203

120

145

Column diameter

mm

Φ92

Φ92

Φ98

Φ125

Main motor power

KW

1.1

1.1

1.0

1.1/1.5

Overall dimensions

mm

1430x660x320

1430x660x320

570x815x1810

570x810x2110

N.W./G.W.

kg

98/108

118/128

190/240

450/490
