1.Base is box welded structure with strong rigidity and good stability.

2. Main transmission part: the worm gear is made of tin bronze material, the worm is hardened and ground, and the worm gear box is processed by CNC machining center with Meehanite cast iron.

3. Hydraulic control cutting feed, hydraulic vice clamping.

4. Rapid feed, work feed automatic conversion, with the sawing workpiece size automatically adjust the working height, to provide work efficiency.

5. The surface of the column is very wear-resistant, the guide sleeve is made of self-lubricating wear-resistant material. The clearance between the two is very small, good verticality .

6. Drum type feeding and unloading worktable, stable feeding and clamping.

7. It can cut all kinds of cast steel ingot or pipe, forged steel parts and various shaft parts.
