1.Base is box welded structure with strong rigidity and good stability.

2. Main transmission part: the worm gear is made of tin bronze material, the worm is hardened and ground, and the worm gear box is made of Meehanite cast iron and processed by CNC machining center.

3. The blade is equipped with bearing guide device, fine-tuned, long service life.

4. The whole machine can be rotated 45°, the length can be automatically set after positioning, the angle can be manually rotated and installed with a pressing device. Saw frame contact workpiece inclination 100:8, easy to operate.

5. Rapid feed, work feed automatic conversion, with the sawing workpiece size automatically adjust the working height, to provide work efficiency.

6. HBS-500S column surface hard chrome plating tight grinding is very wear-resistant, the guide sleeve is made of self-lubricating wear-resistant material, the clearance between the two is very small, good verticality.

7. Mainly used for sawing all kinds of cast steel ingot or pipe, forged steel parts and various shaft parts.
