1. The bed adopts high strength cast iron, stable structure.

2. Mitsubishi PLC touch screen control. Nc feed and NC reciprocating, two axis NC.

3. The machine guide adopts double V type preloading, high precision cross roller guide, high precision, good rigidity.

4. High-speed large-power electric grinding wheel shaft, powered by static inverter, low energy consumption, low noise.

5. The workpiece feed mechanism adopts servo motor to control the ball screw for feed and correction compensation.
