Max swing over bed

mm

360

360

360

Max swing over cross slide

mm

212

212

215

Max swing over gap

mm

490

490

506

Distance between centers

mm

750; 1000

750; 1000

1000

Width of bed

mm

187

187

186

Spindle bore and taper

mm

Φ38;  D1-4

Φ38;  D1-4

Φ38;  D1-4

Spindle speeds

rpm

70～2000   (8 steps)

70～2000   (8 steps)

70～2000   (8 steps)

Metric threads

mm

0.2～5 (28 kinds)

0.4～7 (27 kinds)

0.45～10 (23kinds)

Inch threads

T.P.I.

8～112   (36 kinds)

4～56   (36 kinds)

3-1/2～80   (38 kinds)

Module threads

mm

0.2～3   (22 kinds)

0.2～3.5   (20 kinds)

--

Diametral pitch threads

D.P.

8～112   (36 kinds)

8～120   (3 2kinds)

--

Longitudinal feeds range

mm

0.050～0.696   (36 kinds)

0.097～2.713

0.111~0.967(R); 0.37~0.989(L)

Cross feeds range

mm

0.013～0.188   (36 kinds)

0.033～0.933

0.03~0.804(R); 0.010~0.268(L)

Tailstock quill Taper; Travel

mm

MT.3; 100

MT.3; 95

MT.3; 95

Main motor power

KW

1.5

1.5

1.5

Overall   dimensions

mm

1925/1950x750x1510

1925/1950x750x1510

2000x760x1500

N.W./G.W.

kg

610/650; 660/700

610/650; 660/700

635/700
