Capacity

Swing over bed

mm

360

Swing over   cross slide

mm

200

Swing over gap

mm

470

Center   distance

mm

1000

Bed width

mm

220

Spindle

Taper；Bore

mm

D1-5; φ38

Speed

rpm

60-2000 (9 steps)

Motor power

kW

2.2

Travel

Cross slide / Compound slide

mm

195/80

Feeds

Longitudinal

mm

0.03-0.42

Cross

mm

0.015-0.21

Threads

Metric

mm

0.25-9 (20   kinds)

Inch

T.P.I.

4-73 (33 kinds)

Module

mm

0.25-3.5 (12   kinds)

Diametral pitch

D.P.

8-108 (30 kinds)

Tailstock

Taper/Dia./Travel

mm

MT.3/φ40/80

others

Overall dimensions

mm

1810x770x1170

weight

kg

850
