Capacity

Swing over bed

mm

360

Swing over cross slide

mm

223

Swing over gap

mm

502

Center distance

mm

1000

Bed width

mm

               187

Spindle

Taper；Bore

mm

          D1-5; φ52

Speed

rpm

70-2000 (8 steps)

Motor power

kW

1.5

Travel

Cross slide /   Compound slide

mm

160/95

Feeds

Longitudinal

mm

0.052-1.392 (32 kinds)

Cross

mm

0.014-0.380 (32   kinds)

Threads

Metric

mm

0.4-7 (26 kinds)

Inch

T.P.I.

4-56 (34 kinds)

Tailstock

Taper/Dia./Travel

mm

MT.3/φ32/100

others

Overall dimensions

mm

1825x750x1600

weight

kg

700
