Swing over bed

mm

360

Swing over cross slide

mm

224

Swing over gap

mm

502

Distance between centers

mm

750,1000

Width of bed

mm

186

Spindle bore

mm

Φ38 or Φ52

Spindle nose and taper

D1-4 or D1-5,   MT.5

Spindle speeds

rpm

70～2000 (8 steps)

Metric threads

mm

                          0.1～7 (44 kinds)

Inch threads

T.P.I.

4～112 (42 kinds)

Tailstock quill Dia.; Taper; Travel

mm

Φ32;  MT.3;  100

Main motor   power

KW

1.5

Overall dimensions

mm

1600/1800x740x1300

Weight

kg

560, 600
