Swing over bed

mm

210

Swing over cross slide

mm

110

Distance between centers

mm

320

Width of bed

mm

135

Spindle bore

mm

Φ20

Spindle taper

MT.3

Spindle speeds (6 steps)

rpm

125～2000

Metric threads

mm

0.4～3

Inch threads

T.P.I.

10～44

Longitudinal feeds

mm/r

0.1～0.2

Tailstock quill taper and travel

mm

MT.2; 65

Main motor power

W

550

Weight

machine

kg

108

stand

kg

22
