MB‑B Features:

1. CNC auto feeding, auto rotating angle and hydraulic pipe bending.

Optional: Pipe bending in servo motor.

2. CNC 3D automatic bending machine is suitable for bends of three‑dimension, it is single layer.

3. It is controlled by CNC,Weinview touch screen, Mitsubishi PLC,which is very stable for machine running.

4. Feeding axis and rotating axis are driven by servo motors, high precision, good stability.

5. Bending and PDA are hydraulic cylinder drive.

6. The electrical system has fans which can keep cold.

7. It has the function of backing mandrel which can be controlled in the touch screen.

8. The movable foot switch can automatically start, stop and emergent stop which is high safety.

9. The coolant system (optional) which makes machine more stable.
