Features：

1. Electronic Control System: Adopts a combination of servo drives, servo motors, and CPUs produced by Mitsubishi, a world-renowned controller brand, featuring strong performance and excellent stability.

2. Taiwan Weinview Touch Screen System: The extra-large CPU can store up to 350 groups of file edits.

3. Automatic Error and Fault Detection Function: It can automatically detect errors and faults and display them on the screen, enabling operators to easily troubleshoot.

4. Processing Data Input: All processing data is input via the touch screen. For each pipe bend, compensation values, speed, and demolding gaps can be set according to changes in different materials.

5. Independent Programming for Each Bend: For each bend of the same pipe, 5 action sequences and 10 speed segments can be programmed independently, allowing operators to use them in combination. This improves work efficiency and reduces pipe interference points.

6. Multi-Language Support for Touch Screen: The touch screen supports switching between Chinese and English. The display of other languages can also be ordered according to requirements.

7. Flexible Feeding Methods: The feeding method can be selected as straight feeding or pinch feeding according to different needs, and it can automatically convert XYZ coordinates into YBC processing values.

8. Heat Dissipation for Electronic Control System: The electronic control system is equipped with a heat exchanger for automatic heat dissipation, ensuring the service life of the electronic control system.

9. Automatic Oil Injection Lubrication System: The machine is equipped with an automatic oil injection lubrication system, which facilitates maintenance and extends the service life of the equipment.

10. Manual Fine-Tuning and Automatic Position Memory: The settings of the feeding trolley's feeding position, safety devices, digital model interference position, and guide mold interference position can be finely adjusted manually, and the positions are automatically memorized. This eliminates errors caused by manual measurement and losses due to machine collisions.

11. Pre-Action Detection of Feeding Axis: The feeding axis will automatically detect before moving to avoid collision with the machine.

12. Decomposed Action for Solid Bending: During solid bending, decomposed actions can be selected to observe interference points and modify the work process, thereby improving efficiency.
