Max. drilling dia. (steel)

mm

42

Max. tapping dia. (steel)

mm

M30

Max. milling dia.

mm

80

Distance from spindle to table

mm

760

Ram travel

mm

590

Spindle travel

mm

200

Spindle taper

MT.4

Spindle speeds (variable)

rpm

50-2000

Spindle feeding (6 steps)

mm/r

0.08-0.5

Max. up/down travel of spindle box

mm

400

Swivel angle of spindle box

degree

±90°

Table size

mm

1200x500

Column dia.

mm

220

Main motor power

kW

2.2

Overall dimensions

mm

1910x1200x2400

Weight

kg

2610
