Max. drilling capacity

mm

Φ32

Spindle taper

MT.3

Spindle travel

mm

120

Spindle speeds (4 steps)

rpm

175,432,693,980

Distance from spindle to column

mm

390-870

Distance from spindle to table

mm

50-850

Table size

mm

800x430

Column dia.

mm

160

Spindle motor power

kW

1.5

Z-axis feed motor power

kW

--

Packing size

mm

1600x720x1885

N.W./G.W.

kg

1160/1250
