Table size

mm

1320x320

1700x400

Table travel (X,Y,Z)(manual/auto)

mm

700x255x350/

680x240x330

800x280x330

900x315x385/

880x300x365

920x330x450

T-slot (No./width/distance)

mm

3-18-70

3-18-90

Table load

kg

500

320

800

500

Table feed

mm/min

X:23.5-1180(18steps)

Y:15-786(18steps)

Z:8-394(18 steps)

X/Y:6-3200

Z:3-1600

X/Y:23.5-1180(18steps)

Z:8-394(18 steps)

X/Y:6-3200

Z:3-1600

Table rapid feed (X,Y,Z)

mm/min

2300/1533/770

6000/6000/3000

2300/2300/770

6000/6000/3000

Spindle taper

ISO50

ISO50

Spindle   speeds (18 steps)

rpm

30-1500

30-1500

Swivel angle of milling head

degree

±45°

±45°

Spindle   nose to table surface

mm

60-410

60-390

130-515

50-500

Spindle axis to column

mm

350

450

Main motor power

kW

7.5

11

Feed motor power (X,Y,Z)

kW

1.5

15/15/22   Nm

3

15/15/22   Nm

Overalldimensions

mm

2294x1770x1904

1929x2055x1960

2400x2200x2250

2310x2200x2394

Weight

kg

2800

2800

4250

4250
