1. The lifting direction is servo motor and drive, PLC and electronic hand wheel.

2. The left and right directions are hydraulically driven; The front and rear directions of CTM-400B/500B are hydraulic + manual drive, and the front and rear directions of other models are variable frequency motor + manual drive.

3. Each guideway adopts forced lubrication to ensure that the guideway works under the protection of oil film and prolong the service life of the machine tool.

4. The cooling water tank adopts the funnel precipitation separation structure, and the magnetic separator or magnetic paper separator filter water tank can be selected to improve the grinding quality of the machine surface

5 Spindle bearing adopts bobbin tile structure, strong impact resistance, suitable for heavy duty cutting, high processing efficiency.
