Table size

mm

2500x575

Table travel (X, Y)

mm

1800(2000)x600

Headstock travel (Z)

mm

V: 900

Table feed speed ( X/Y)

mm/min

20~2200

Table rapid feed speed (X/Y)

mm/min

3000

Max. load of table

kg

3000

Min. distance from horizontal spindle to table

mm

30

Min distance from vertical spindle to table

mm

49

Distance from spindle to column

mm

110

No./width/distance of T-slot

mm

3-22-152

Spindle taper

ISO50

Spindle speeds

rpm

40~1200 (12 steps)

Headstock feed speed (Z)

mm/min

12-1320

Headstock rapid feed speed (Z)

mm/min

1800

Spindle quill travel

mm

--

Spindle quill auto-feed

mm/r

--

Main motor power

KW

11

Overall dimensions

mm

4300x3200x3300

Weight

kg

10000
