Sawing capacity

Round bar

mm

12-75

12-90

20-120

Square bar

mm

12-58

12-70

20-80

Round tube

mm

12-75

12-90

20-120

Square tube

mm

12-58

12-70

20-80

Spindle box

TCT super hard blade

mm

285t2.0

315t2.25

380t2.6

Spindle motor

kW

11

11

11/15

Spindle speed

rpm

30-150

30-150

20-120

Cut-off feeding mode

AC servo motor, ball screw, linear guideway

Main clamp mode

Hydraulic,   one set of vertical and horizontal clamps

Blade debris removal device

Passive round wire brush

Gear backlash compensation device

Through   shaft coupling magnetic powder brake

Feeding clamp(vice)

Feeding drive mode

AC servo motor, ball screw, swing feed,   linear guideway feeding

Feeding clamp mode

Hydraulic,   horizontal clamp

Material front end removal length

mm

10-99 (No cutting head is optional)

Material rear end residual length

mm

65+a

10-99 (No cutting head is optional)

75+a

Single feeding length

mm

10-800

10-800

10-800

Automatic feeding device

Allowable material placement length

mm

3000-6000

Feeding method

Pre-arranged, Hydraulic lift

Hydraulic station

Hydraulic pump type

Variable displacement vane pump

Hydraulic drive motor

kW

2.25(4P)

2.25(4P)

3.75(4P)

Rated pressure of hydraulic system

MPa

4-6

4-6

4-6

Hydraulic oil capacity

L

70

90

110

Others

Overall dimensions

mm

7500x2900x2100

7500x2900x2100

7700x3200x2250

Weight

kg

5100

5250

6000
