Sawing capacity

Round bar

mm

40-150

70-180

80-200

Square bar

mm

40-105

70-140

80-150

Round tube

mm

40-150

70-180

80-200

Square tube

mm

40-105

70-140

80-150

Spindle box

TCT super hard blade

mm

460t2.7

520t3.0

630t3.4

Spindle motor

kW

18.5

22

30

Spindle speed

rpm

20-120

20-100

20-80

Cut-off feeding mode

AC servo motor, ball screw, linear guideway

Main clamp mode

Hydraulic,   one set of vertical and horizontal clamps

Blade debris removal device

Active round wire brush

Gear backlash compensation device

Passive   round wire brush

Feeding clamp(vice)

Feeding drive mode

Through shaft coupling magnetic powder brake

Feeding clamp mode

AC servo   motor, ball screw, swing feed, linear guideway feeding

Material front end removal length

mm

Hydraulic, horizontal clamp

Material rear end residual length

mm

85+a

120+a

120+a

Single feeding length

mm

10-800

10-800

10-800

Automatic feeding device

Allowable material placement length

mm

3000-6000

Feeding method

Pre-arranged, Hydraulic lift

Hydraulic station

Hydraulic pump type

Variable displacement vane pump

Variable displacement piston pump

Hydraulic drive motor

kW

3.75(4P)

5.5(4P)

5.5(4P)

Rated pressure of hydraulic system

MPa

4-6

5-7

6-8

Hydraulic oil capacity

L

120

120

160

Others

Overall dimensions

mm

7700x3400x2250

7700x3400x2250

8300x3850x2570

Weight

kg

6700

7000

9800
