Max. drilling dia.

mm

Ф40

Ф50

Max. feed force

N

16000

16000

Max. spindle torque

Nm

350

350

Spindle taper

MT.4

MT.5

Spindle travel

mm

250

250

Spindle head travel

mm

200

200

Spindle speeds

rpm

31.5～1400(12 steps)

31.5～1400(12 steps)

Feed speeds

mm/r

0.056～1.8(9 steps)

0.056～1.8(9 steps)

Table travel

mm

300

300

Table size

mm

560x480

As above

560x480

As above

Distance from spindle to table

mm

750

750

Distance from spindle to column

mm

335

335

Main motor power

KW

3

3

Overall dimensions

mm

1090x905x2530

1090x910x2530

Weight

kg

1250

1300

1250

1300
