Max. drilling capacity

mm

Φ32

Φ35

Φ40

Φ50

Max. tapping capacity

mm

M22

M22

M24

M27

Distance from spindle to column

mm

320

320

360

380

Distance from spindle to table

mm

630

585

615

590

Distance from spindle to base

mm

1185

1140

1195

1175

Spindle travel

mm

155

155

190

200

Spindle headstock travel

mm

285

--

--

--

Spindle taper

MT.4

MT.4

MT.4

MT.4

Spindle speed steps

step

12

12

9

9

Spindle speed range

rpm

125~3030

125~3030

72~2150

70~2100

Spindle feed range

mm/min

0.1;0.2;0.3

0.1;0.2;0.3

0.12;0.24;0.42

0.12;0.23;0.40

Spindle feed type

Electro-magnetic clutch

Swivel angle of table

degree

±45°

±45°

±45°

±45°

Table travel

mm

415

545

550

530

Table size

mm

500x420

500x420

570x480

600x500

Base size

mm

370x360

370x360

410x395

445x435

Motor power

KW

1.0/1.2

1.0/1.2

2

2.2

Overall dimensions

mm

850x500x2220

860x515x2170

945x570x2290

1000x600x2260

Weight

kg

560

475

600

710
