Max. drilling capacity

mm

20

25

28

32

35

Taping

--

M24

--

--

--

Swing

mm

380

450

430

515

515

Spindle taper

MT.2

MT.2

MT.2

MT.3

MT.3

Spindle travel

mm

130

120

130

150

150

Spindle speeds (16 steps)

rpm

140-3470

160-3000

140-3450

140-3600

140-3600

Column dia.

mm

70

92

80

92

92

Distance from spindle to table

mm

431

680

730

730

730

Distance from spindle to base

mm

685

1160

1219

1180

1180

Table size

mm

290x290

330x330

330x330/377x377

475x425

475x425

Base size

mm

425x250

480x280

519x280

613x449

613x449

Motor power

kW

0.75

0.75 or 1.1

1.1

1.5

1.75

Overall height

mm

1610

1635

1638

1750

1750

Packing size

mm

1448x670x350

1430x640x315

1448x670x350

1458x698x355

1458x698x355

N.W./G.W.

kg

71/75

80/84

89/94

118/123

120/125
