Drilling capacity

mm

50

50

50

Vertical milling

mm

25

25

25

Spindle taper

MT.4/ISO40

ISO40

ISO40

Spindle travel

mm

120

120

120

Spindle speeds

Vertical

rpm

60~1500(8   steps)

90~2000(8   steps)

90~2000(8   steps)

Horizontal

rpm

40~1300(12 steps)

40~1300(12 steps)

40~1300(12 steps)

Auto-feeding

mm

0.08, 0.15,   0.25

0.1, 0.15,   0.3

0.1, 0.15,   0.3

Table size

mm

1250x320

1120x260

1270x320

Table travel

mm

600x300x300

600x270

600x290

Distance from spindle to table

mm

100~400

100~400

120~500

Table power feeds

mm/min

X/Y: 22~555

(8 steps);   Rapid:810  Z:560

X/Y: 24~402

(9 steps)   Z:422

X/Y/Z: 30~720

(8 steps)   Rapid:1070

Main motor power

KW

1.5(V), 2.2(H)

2.2(V), 2.2(H)

2.2(V), 2.2(H)

Overall dimensions

mm

1700x1480x2150

1520x1290x2150

1680x1640x2200

Weight

kg

1550

1450

1650
