Table size

mm

1320x320

1700x400

Table travel (X,Y,Z)(manual/auto)

mm

700x255x320/

680x240x300

800x350x280

900x315x380/

880x300x360

920x380x330

T-slot (No./width/distance)

mm

3-18-70

3-18-90

Table load

kg

500

320

800

500

Table feed

mm/min

X/Z:23.5-1180(18steps)

Y:8-394   (18steps)

X/Z:6-3200 Y:3-1600

X/Z:23.5-1180   (18steps)  Y:8-394 (18steps)

X/Z:6-3200  Y:3-1600

Table rapid feed (X,Y,Z)

mm/min

2300/2300/770

6000/3000/6000

2300/2300/770

6000/3000/6000

Ram stroke

mm

500

500

700

700

Spindle taper

ISO50

ISO50

Spindle speeds (18 steps)

rpm

30-1500

30-1500

Spindle axis to table surface

mm

30-350

20-370

30-410

30-410

Main motor power

kW

7.5

11

Feed motor power

kW

1.5

12/12/22 Nm

3

12/12/22 Nm

Overall dimensions

mm

2294x1770x1665

1929x2055x1960

2560x2130x1800

2310x2200x2394

Weight

kg

2650

2800

3850

3850
