Table size

mm

350x1600; 350x2000

350x1600; 350x2000

Table travel

Manual

mm

1000/1400x300x430

1000/1400x300x430

Auto

mm

900/1300x280x400

900/1300x280x400

T-slots (No./Width/Distance)

mm

5-18-65

5-18-65

Table swivel angle

degree

±45°

±45°

Distance from   horizontal spindle to table

mm

30~430

30~430

Distance from vertical spindle to table

mm

30~350

50~550

Spindle taper

ISO50

ISO40/ISO50

Spindle speeds

rpm

35~700

35~700/90~1450

Table feed range (longitudinal/cross)

mm/min

15~750

15~750

Table feed range (vertical)

mm/min

5~250

5~250

Rapid feed of   table (X/Y/Z)

mm/min

1920/1920/640

1920/1920/640

Main motor power

KW

H:7.5/4.5(2-speed motor)

H:7.5/4.5(2-speed motor); V:3

Feed motor power

KW

1.8/1.4

1.8/1.4

Overall dimensions

mm

2190x2230x2140

2190/2590x2230x2140

Weight

kg

2610; 2800

3200; 3500
