Swing over bed

mm

280

Swing over cross slide

mm

150

Distance between centers

mm

610

Width of bed

mm

180

Spindle bore

mm

Φ26

Spindle taper

MT.4

Spindle speeds (6 steps)

rpm

125～2000

Metric threads

mm

0.1～3.5

Inch threads

T.P.I.

8～35

Longitudinal feeds

mm/r

0.1～0.25

Tailstock quill taper and travel

mm

MT.3; 80

Main motor power

W

750

Weight

machine

kg

218

stand

kg

50
