Swing over bed

mm

250

Swing over cross slide

mm

140

Distance between centers

mm

400/550/750

Width of bed

mm

135

Spindle bore

mm

Φ21

Spindle taper

MT.3

Spindle speeds (6 steps)

rpm

125～2000

Metric threads

mm

0.1～2.5

Inch threads

T.P.I.

8～56

Longitudinal feeds

mm/r

0.1～0.2

Tailstock quill taper and travel

mm

MT.2; 65

Main motor power

W

550

Weight

machine

kg

112,116,126

stand

kg

27,27,27
