Features:

1. The entire machine adopts an integral frame structure, with the machine body and slide block welded using new materials and sheet metal forming technology.

2. The pump station and electrical box are mounted on the machine body, forming an integral structure that requires no disassembly, facilitating transportation and installation.

3. It is equipped with four-corner eight-sided guide rails, featuring high guiding accuracy, strong anti-eccentric load capacity, and centralized lubrication.

4. A large-diameter liquid filling valve manufactured with professional technology is adopted to meet the process requirements of the hydraulic press for rapid downward movement and rapid return stroke, which greatly improves work efficiency and creates more value for users.

5. The hydraulic system adopts a cartridge valve integrated system, ensuring reliable operation, long service life, and low hydraulic impact.

6. The cylinder block and piston rod of the oil cylinder are made of materials with patented technology, which enhances the working reliability of the oil cylinder.

7. The working pressure, speed, and stroke range of the slide block can all be adjusted according to process requirements.
