Max. drilling dia.

mm

50

63

80

Max. tapping dia.

mm

M36

M42

M52

Distance between spindle and column

mm

350-1600

450-2000

500-2500

Distance between spindle and base

mm

320-1220

400-1600

550-2000

Column dia.

mm

315

450

550

Spindle taper

MT.5

MT.5

MT.6

Spindle travel

mm

315

400

450

Spindle speeds (16 steps)

rpm

25-2000

20-1600

16-1250

Spindle feeding (16 steps)

mm/r

0.04-3.2

0.04-3.2

0.04-3.2

Main motor power

kW

4

5.5

7.5

Arm lifting motor power

kW

1.5

2.2

3

Table size

mm

630x500x500

800x630x500

1000x800x560

Base size

mm

2400x1000x200

2900x1250x250

3530x1400x300

Overall dimensions

mm

2500x1070x2840

3080x1250x3400

3730x1400x4025

Weight

kg

3500

7000

11000
