1.Features

(1). X,Y-axes linear guideways. Z-axis box way. The X-axis is designed with 2 guideways. The table and workpiece are fully supported with high load capacity, stable precision and high rigidity.

(2). Adopting center-symmetric spindle head (Z-axis) design and T-type ram structure.

(A). The specially designed internal shower temperature control system of the spindle head ensures the accuracy of the spindle and the stability of long time high-speed operation.

(B). Adopt left-right symmetrical double hydraulic cylinder counterweight to balance the top and bottom to ensure the best long term accuracy.

(C).Adopt high power digital servo spindle motor, matched with full gear type two-speed gearbox, high cutting torque, which

can adapt to all kinds of heavy cutting and high precision machining.

(D).Optional: The square ram spindle speed 3200rpm or 4500rpm, especially suitable for heavy cutting and rough machining of large workpieces.

(3).Rich optionals: Milling heads, CTS, RENISHAW measurement tools et.

2.Main specifications
